Radial PROAV2 Passive Stereo Multimedia DI with RCA, 3.5mm, XLR, 1/4" Connectors

Name: Radial PROAV2 Passive Stereo Multimedia DI with RCA, 3.5mm, XLR, 1/4" Connectors
Brand: Cecere's Music
SKU: RA-PROAV2
Price: 449.0 AUD
Availability: InStock

Prezzo regolare $449.00

Spedito dal magazzino (potrebbe essere soggetto a arretrati)

Quantità:

Variante

aggiunto al tuo carrello!

Visualizza carrello o continua lo shopping.

SKU: RA-PROAV2

The ProAV2 is a stereo passive direct box designed for audio-video integrators and technicians, with an array of input connector options to easily interface with a wide range of audio equipment.

Versatile stereo direct box for multimedia applications
Easy to use, ultra-quiet passive design
Transformer isolation eliminates hum and buzz
Handles huge transients without distortion

The Radial ProAV2 is a passive direct box designed to handle the extreme dynamics and frequency range that is now common with digital sources. Linear across the audio range, it exhibits low distortion at all frequencies, amazing signal handling and very little phase shift. The result is a clean, natural sounding rendition that is both noise-free and dependable.

Audio circuit type:	Passive, transformer based
Transformer:	Eclipse ET-DB2, 12:1 ratio
Number of channels:	Dual channel (stereo)
Frequency response:	20Hz ~ 18.5KHz (± 0.2dB)
Dynamic range:	128dB
Total harmonic distortion:	0.01% from 20Hz~20kHz @-10dB
Phase Deviation:	1° @ 100Hz; 8° @ 20Hz
Input Impedance:	140k Ohms, unbalanced
Output Impedance:	150 Ohms, balanced
Maximum Input:	+18dB @ 20Hz

Features

Ground lift
Input Connectors:	1/4", RCA, 3.5mm TRS
Output Connectors:	XLR

General

Construction:	14-gauge steel chassis & shell
Size (L x W x D):	3.25” x 5” x 1.875”
Weight:	0.82kg / (1.8lbs)
Shipping size (L x W x D):	102 x 76 x 165mm (4.00" x 3.00" x 6.50")
Shipping weight:	1.2 kg (2.60 lbs)
Power:	Passive, no power required
Conditions:	For use in dry locations only between 5°C and 40°C
Warranty:	Radial 3-Year, transferable

The ProAV2 is a stereo passive direct box designed for audio-video integrators and technicians, with an array of input connector options to easily interface with a wide range of audio equipment.

Features

Versatile stereo direct box for multimedia applications
Easy to use, ultra-quiet passive design
Transformer isolation eliminates hum and buzz
Handles huge transients without distortion

Specifications

Audio circuit type:	Passive, transformer based
Transformer:	Eclipse ET-DB2, 12:1 ratio
Number of channels:	Dual channel (stereo)
Frequency response:	20Hz ~ 18.5KHz (± 0.2dB)
Dynamic range:	128dB
Total harmonic distortion:	0.01% from 20Hz~20kHz @-10dB
Phase Deviation:	1° @ 100Hz; 8° @ 20Hz
Input Impedance:	140k Ohms, unbalanced
Output Impedance:	150 Ohms, balanced
Maximum Input:	+18dB @ 20Hz

Features

Ground lift
Input Connectors:	1/4", RCA, 3.5mm TRS
Output Connectors:	XLR

General

Construction:	14-gauge steel chassis & shell
Size (L x W x D):	3.25” x 5” x 1.875”
Weight:	0.82kg / (1.8lbs)
Shipping size (L x W x D):	102 x 76 x 165mm (4.00" x 3.00" x 6.50")
Shipping weight:	1.2 kg (2.60 lbs)
Power:	Passive, no power required
Conditions:	For use in dry locations only between 5°C and 40°C
Warranty:	Radial 3-Year, transferable

—

Acquista tutto

Radial PROAV2 Passive Stereo Multimedia DI with RCA, 3.5mm, XLR, 1/4" Connectors
