AGUILAR AG 700 SUPER LIGHT HEAD

THE AG SOUND

Power Output: 700 watts @ 2.67 or 4 ohms, 350 watts @ 8 ohms

Preamp Section: Solid State

Power Section: Class D

Transformer: Switching mode power supply (SMPS)

EQ Section:

• Bass: +/- 17 dB @ 40 Hz
• Deep: +6 dB <250 Hz
• Low Mid: +/- 15 dB @ 300 Hz
• High Mid: +/- 14dB @ 800 Hz
• Treble: +/- 14 dB @ 4 kHz
• Bright: +6 dB >3 kHz, shelving

-10dB input pad

Tuner output

Inputs: One 1/4″ input jack, compatible with all active and passive basses

Speaker Outputs: One Neutrik Speakon speaker outputs

Effects Loop: Series operation. Adds 6 dB of additional gain, making it useful for a broad range of effects units

Balanced Output: XLR balanced output with pre/post EQ and ground lift switch

Cooling: Two high-quality whisper fans with thermal speed control
