Name: Eminence LEGEND1058 10in Guitar Speaker 75w 8 Ohm
Brand: Eminence
SKU: LEGEND1058
Price: 279.99 AUD
Availability: InStock

Free Shipping to metro areas for orders over $100

Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100Free Shipping to metro areas for orders over $100

Series	Legends
Model	Legend 1058
Application	10" Open or Closed Back
Configuration	1, 2, or 4 X 10"
Low End Response	Moderate
Low End Shape	Chunky
Mid-Range Response	Moderate
Mid-Range Shape	Warm
High-End Response	Moderate
Volume/Power	Louder
Overall Coloration*	Vintage American tone with punchy lows and warm, smooth, bluesy mids and highs. Fatter Legend 1028K tone with more depth.
Break-up Modes	Medium
Power Range	Up to 75 watts
Instrument*	Lead/Rhythm Guitar
Genre of Music*	Country, Blues, Rock, Jazz

SPECIFICATION
Nominal Basket Diameter	10", 254 mm
Nominal Impedance*	8 Ω
Power Rating*
Program Power	N/A
Watts	75 W
Resonance	97 Hz
Usable Frequency Range	100 Hz - 5 kHz
Sensitivity*	98.7 dB
Magnet Weight	16 oz.
Gap Height	0.25", 6.4 mm
Voice Coil Diameter	1.5", 38 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs)	97 Hz
DC Resistance (Re)	7.49 Ω
Coil Inductance (Le)	0.56m H
Mechanical Q (Qms)	17.78
Electromagnetic Q (Qes)	1.21
Total Q (Qts)	1.13
Compliance Equivalent Volume (Vas)	26.4 liters / 0.93 cu.ft.
Peak Diaphragm Displacement Volume (Vd)	0 cc
Mechanical Compliance of Suspension (Cms)	0.16 mm/N
BL Product (BL)	8 T-M
Diaphragm Mass Inc. Airload (MMs)	17 grams
Efficiency Bandwidth Product (EBP)	80
Maximum Linear Excursion (Xmax)	0 mm
Surface Area of Cone (Sd)	344.9 cm2
Maximum Mechanical Limit (Xlim)	N/A
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed	Acceptable
Vented	Acceptable
Driver Volume Displaced	0.033 cu.ft. / 0.93 liters
Overall Diameter	10.11", 256.8 mm
Baffle Hole Diameter	9.13", 231.9 mm
Front Sealing Gasket	Yes
Rear Sealing Gasket	Yes
Mounting Holes Diameter	0.23", 5.8mm
Mounting Holes B.C.D.	9.6", 243.8mm
Depth	3.5", 88.9 mm
Net Weight	4.4 lbs, 2 kg
Shipping Weight	5.4 lbs, 2.45 kgs
MATERIALS OF CONSTRUCTION
Coil Construction	Copper voice coil
Coil Former	Polyimide former
Magnet Composition	Ferrite magnet
Core Details	Non-vented core

Basket Materials	Pressed steel basket
Cone Composition	Paper cone
Cone Edge Composition	Paper cone edge
Dust Cap Composition	Solid composition felt dust cap

—
