    Eminence MANOWAR 12in Speaker 120w 8 Ohm

    Regular price $319.99
    In Stock

    SKU: MANOWAR

    The Eminence Man O War guitar speaker is the work horse of tone. A proven and revered sound, very loud and responsive/articulate in every register. Chunky and solid sound with a little top end sparkle.

    Series Redcoats
    Model Man O War
    Application 12" Open or Closed Back
    Configuration 1, 2, or 4 X 12"
    Low End Response Moderate
    Low End Shape Chunky
    Mid-Range Response Aggressive
    Mid-Range Shape Crisp
    High-End Response Aggressive
    Volume/Power Loudest
    Overall Coloration* A proven and revered sound,  very loud and responsive/articulate in every register.  Chunky and solid sound with  a little top end sparkle
    Break-up Modes Slow
    Power Range Up to 120 watts
    Instrument* Lead/Rhythm  Guitar, Harmonica
    Genre of Music* Great for College Rock, Classic Rock, Grunge, and Heavy Metal

    SPECIFICATION
    Nominal Basket Diameter 12", 305 mm
    Nominal Impedance* 8 Ω
    Power Rating*
    Program Power N/A
    Watts 120 W
    Resonance 91 Hz
    Usable Frequency Range 80 Hz - 5 kHz
    Sensitivity* 101.6 dB
    Magnet Weight 38 oz.
    Gap Height 0.312", 7.9 mm
    Voice Coil Diameter 1.75", 44 mm
    THIELE & SMALL PARAMETERS
    Resonant Frequency (fs) 91 Hz
    DC Resistance (Re) 6.2 Ω
    Coil Inductance (Le) 0.43m H
    Mechanical Q (Qms) 11.66
    Electromagnetic Q (Qes) 0.72
    Total Q (Qts) 0.68
    Compliance Equivalent Volume (Vas) 38 liters / 1.34 cu.ft.
    Peak Diaphragm Displacement Volume (Vd) 41.6 cc
    Mechanical Compliance of Suspension (Cms) 0.1 mm/N
    BL Product (BL) 12.3 T-M
    Diaphragm Mass Inc. Airload (MMs) 31 grams
    Efficiency Bandwidth Product (EBP) 127
    Maximum Linear Excursion (Xmax) 0.8 mm
    Surface Area of Cone (Sd) 519.5 cm2
    Maximum Mechanical Limit (Xlim) N/A
    MOUNTING INFORMATION
    Recommended Enclosure Volume
    Sealed Acceptable
    Vented Acceptable
    Driver Volume Displaced 0.071 cu.ft. / 2 liters
    Overall Diameter 12.03", 305.6 mm
    Baffle Hole Diameter 11.07", 281.2 mm
    Front Sealing Gasket Yes
    Rear Sealing Gasket Yes
    Mounting Holes Diameter 0.25", 6.4mm
    Mounting Holes B.C.D. 11.59", 294.4mm
    Depth 5.2", 132.1 mm
    Net Weight 8.1 lbs, 3.67 kg
    Shipping Weight 9.9 lbs, 4.49 kgs
    MATERIALS OF CONSTRUCTION
    Coil Construction Copper voice coil
    Coil Former Polyimide former
    Magnet Composition Ferrite magnet
    Core Details Non-vented core

    Basket Materials Pressed steel basket
    Cone Composition Paper cone
    Cone Edge Composition Paper cone edge
    Dust Cap Composition Zurette dust cap
